Integrated connector modules specifically designed for industrial Ethernet apps

August 27, 2018 By Lee Teschler Leave a Comment

A MagJack Integrated Connector Module (ICM) is specifically designed for Industrial Ethernet applications. All variants meet the IEEE 802.3 10/1000Base-T and 1GBase-T electrical requirements including RL, IL, Hi-pot and Common Mode parameters.

TRP Connector Industrial Ethernet MagJack ICMs satisfy the growing demand for integrated trp-industrial-ethernet-icmsconnectors used in operating robots and machines, on the factory floor. These ICMs support 10/100Base-T non-PoE, PoE and 1GBase-T Ethernet applications and operate at temperatures between -40 and 85°C, allowing the ICM to maintain signal integrity in harsh conditions. TRP
MagJack ICMs have IR reflow compatibility, tape-and-reel packaging, optional LEDs and can be automatically inserted on to the PCB for an economical solution.

Ideal applications include; Industrial Ethernet controllers, Machine control boards, Ethernet lighting controls, Industrial Wireless access points and Industrial video display units. The part numbers are 2250015-1, 2250056-1 and 2250066-1.

Products are now available at Digi-Key, Mouser, and Avnet. For technical information, visit the website at belfuse.com/magnetic-solutions or download the data sheet at https://belfuse.com/resources/icms/ds-mag-industrial-ethernet-magjack-icms.pdf. Further assistance is available from Bel Magnetics by email techhelp@belf.com or at (858) 842-1970.

Filed Under: connector components, New Product Announcement, Products Tagged With: belfuse, cinchconnectivity
